Sub-Zero 249R

Planning Information
Undercounter Model 249R
Dimensions in parentheses are in
millimeters unless otherwise specified.
5
FRAMED PANELS
Framed door panels must be
1
/4" (6) thick around the
perimeter. If the panel is thicker than
1
/4" (6), an edge must
be routed around the panel to ensure a proper fit. Refer to
the illustrations on this page.
IMPORTANT NOTE: The weight of the panel cannot
e
xceed 20 lbs (9 kg).
FRAMED PANEL DIMENSIONS
WIDTH HEIGHT
Door Panel 23
5
/8" (600) 30 " (762)
Handle Recess Location (A)
15" (381)
Maximum P
anel Weight 20 lbs
(9 kg)
F
ramed door panel
1
/4"
(6) thick or less
Framed door panel thicker than
1
/4" (6)
P
ANELS
1
/4" (
6) THICK OR LESS
1
/4" (6) Panel
Trim reveal
1
/4" (6) min
PANELS THICKER THAN
1
/4" (6)
Trim reveal
1
/4" (6) min
Rout to
1
/4" (6)
thickness
W
H
A
4"
F
ramed Door Panel
