PAGE 103
700-3 SERIES - BASE UNITS
Service Input Operations
» Auto Model Configuration Mode
If a new main control board is installed during a service call,
double dashes ( - - ) will appear on the LCD indicating the board
must be configured for the model it was installed into.
1. Open bottom drawer.
2. With unit on - Press COLDER or WARMER key to toggle
through model codes, then stop when proper code is dis-
played (See Model Code Table on next page).
3. Press UNIT ON/OFF key to store configuration.
» Manual Entry Model Configuration Mode
If control board configuration needs to be verified or changed:
1. Open bottom drawer.
2. With unit on - Press COLDER and UNIT ON/OFF keys
simultaneously, then release.
3. Press Bell ON/OFF and UNIT ON/OFF keys simultaneous-
ly, then release.
4. Press COLDER or WARMER key to toggle through model
codes, then stop when proper code is displayed (See
Model Code Table on next page).
3. Press UNIT ON/OFF key to store configuration.
