Lighting Information
CABINET LIGHTING
For models 424G and 424FSG, rope-style lighting is
mounted to the top of the cabinet and cascades down
the entire front of the wine storage unit. Refer to the
illustration below.
Models 427G, 427RG and WS-30 have discreet interior
lighting provided in two places. Rope-style lighting is
mounted to the top of the cabinet and additional lighting
is mounted in the control panel to illuminate the display
shelf.
These lights have an extended life and it should be some
time before they need to be replaced. If you have problems
with the cabinet lighting or need replacements, contact
Sub-Zero factory certified service or call 800-222-7820.
Wine Storage Use & Care 15
subzero.com
DRAWER LIGHTING—MODEL 427RG
Lighting is recessed into the top area of each bulk storage
drawer compartment of model 427RG. Refer to the illus-
tration below.
To replace a light bulb in the drawer compartment, you
must pull the drawer out to its maximum extension. It is
recommended that you remove the drawer. Refer to
drawer removal on page 13.
Remove the 15-watt light bulb by unscrewing it from its
socket and replace the bulb. Replace the drawer as
outlined on page 13.
Cabinet lighting (427G,
427RG and WS-30).
Drawer lighting (427RG).
Shut off power to the unit before replacing light bulbs.
Wear protective gloves when handling bulbs.
