6 | Sub-Zero Customer Care 800.222.7820
Anti-Tip Bracket
WARNING
To prevent the unit from tipping forward, the anti-tip
bracket must be installed.
MODEL 424G
The anti-tip bracket should be attached to the wall behind
the unit with the bracket ange located
1
/4" (6) above the top
of the unit. Refer to the illustration below. Failure to properly
position the anti-tip bracket will prevent proper engagement.
For installations that cannot accommodate the anti-tip
bracket, a countertop bracket is provided to secure the unit
to the countertop. Refer to the illustration below.
1
/4" (6)
ANTI-TIP
BRACKET
COUNTERTOP
BRACKET
Anti-tip bracket (424G). Countertop bracket.
MODEL 424FSG
The back of the anti-tip bracket must be installed 24
5
/8"
(625)
from the front and centered behind the unit. Refer to
the illustration below. Refer to page 13 for wood and con-
crete oor applications.
MODEL 424G / 424FSG SITE PREPARATION
ANTI-TIP BRACKET
Anti-tip bracket (424FSG).
