Model WS-30 Installation 32
Standard Installation Opening Dimensions
Framed, Overlay and Stainless Steel Models
IMPORTANT NOTE: If two units are installed side by side,
refer to page 34 for dual standard installations.
Stainless steel models are ready to install out of the box.
24" (610)
OPENING
DEPTH
FRONT VIEWSIDE VIEW
T
OP VIEW
29
1
/2" (746)
OPENING WIDTH
24" (610)
OPENING DEPTH
83
3
/4"
(2127)
OPENING
HEIGHT
