Sub-Zero 427R Planning Information

Planning Information
Wine Storage Model 427R
11
A
A
A
A) ALL REVEALS ARE 1/8" (3) *DIMENSIONS MAY VARY
SIDE VIEW
2
4"
(610)
PANEL WIDTH
45
3
/8"
(1153)
2
6
3
/4"
*
(679)
13
9
/16"
(345)
16
11
/16"*
(424)
4"*
(102)
80"*
(2032)
34
1
/2"
(876)
*
27"
(686)
FINISHED OPENING
TOE KICK
79
7
/8"*
(2029)
FRAMELESS CABINETRY APPLICATIONS
The illustration below shows a hypothetical installation
of a Model 427R within frameless cabinetry. Review the
illustration, giving particular attention to the overall panel
specifications. Also refer to the full-scale illustrations at
the end of this section for specifics on door openings.
I
MPORTANT NOTE:
D
imensions are based on a
1
/8"
(3)
reveal. A reveal of up to
1
/4" (6) is possible, but panel
dimensions need to be adjusted accordingly.
FRAMELESS CABINETRY
Installation of a Model 427R within
frameless cabinetry.
*Dimensions may vary.
Dimensions in parentheses are in
millimeters unless otherwise specified.
