Sub-Zero 427R Design Guide

Dimensions in
parentheses are in
millimeters unless
otherwise specified.
WINE STORAGE
54
PLANNING INFORMATION
Review the Overall Dimensions and Installation
Specifications illustrations for your Wine Storage
model on the following pages. These specifica-
tions cover all the details you need to know
about space allocation and placement of electri-
cal, whether the models are framed, overlay,
stainless steel or integrated.
All Wine Storage models must be installed so
that the door can open a minimum of 90˚ or you
will have problems pulling the wine shelves out.
Refer to the door clearance and door swing
information.
For corner installations, you need allow for a
minimum 3" (76) filler so the door can open to
90˚. If you are using larger handle hardware, you
will also need to take that into account.
For a maximum 90˚ door opening, use the door
stop built into the hinge system of Model 427.
An optional 90˚ door stop kit for Model 430 is
available from your Sub-Zero dealer.
If you will be connecting the unit to a home
security system, you must allow a minimum of
36" (914) of the system‘s wiring to be routed in
the electrical area designated for your model.
IMPORTANT NOTE: The anti-tip bracket must be
installed to prevent the unit from tipping
forward.
DUAL INSTALLATIONS
If you are installing a Wine Storage unit next to
an existing Sub-Zero unit, you may have to allow
for a filler strip.
If you are installing a Model 427 or 427R Wine
Storage unit next to an existing Integrated
Sub-Zero unit, with 2" (51) or less between the
units, an optional heater kit (BBDUAL or
TTDUAL) will need to be installed to prevent
moisture from forming between the units. This
optional kit is available through your Sub-Zero
dealer.
ELECTRICAL REQUIREMENTS
A 115 V AC, 60 Hz, 15 amp circuit breaker and
electrical supply are required. A separate circuit
servicing only this appliance is required.
All Sub-Zero Wine Storage models are equipped
with a power supply cord with a 3-prong ground-
ing plug, which must be plugged into a mating
3-prong grounding-type wall receptacle. Follow
the National Electrical Code and local codes and
ordinances when installing the receptacle. Refer
to the Installation Specifications illustrations on
the following pages for electrical placement for
your model.
IMPORTANT NOTE: A ground fault circuit
interrupter (GFCI) is not recommended and may
cause interruption of operation.
ACCESSORIES
Optional accessories
are available
through your
Sub-Zero dealer. To
obtain local dealer
information, visit the
Showroom Locator
section of our
website,
subzero.com.
