Planning Information
Built-In Model 601F
Dimensions in parentheses are in
millimeters unless otherwise specified.
4
INSTALLATION SPECIFICATIONS
72
3
/4"
(
1848)
ROUGH
OPENING
HEIGHT
35
1
/2"
(902)
ROUGH OPENING WIDTH
24"
(
610)
R
OUGH
O
PENING
D
EPTH
11"
(279)
3"
(76)
24"
(610)
W
LOCATE WATER SUPPLY
WITHIN BOTTOM SHADED
AREA ONLY
LOCATE ELECTRICAL
WITHIN ENTIRE SHADED AREA
6"
(152)
E
SHUT-OFF
VALVE
E
XTEND WATER LINE
A
PPROX. 36" (914)
F
ROM BACK WALL
FRONT VIEW
TOP VIEW
DIMENSIONS
Finished Rough Opening Width 35
1
/2" (902)
Finished Rough Opening Height 72
3
/4" (1848)
Finished Rough Opening Depth 24" (610)
Location of Electrical Within entire shaded area
Location of W
ater Supply
Within lower shaded area
See Installation Instructions shipped with unit for detailed specifications.
Refer to the Sub-Zero Design Guide pdf file for additional specifications.
