C©MPLETING THE HNSTALLATHON
90 DEGREE DOOR STOP INSTALLATION CHECKLHST
The doors of aHHBuHtdn modeHs open to 130
degrees. For ModeHs 601R, 601RG, 601F, 661,
642, 68B, 632 and 69B, opfionaH 90 ° or 105 ° door
stop kits are avaHabHe through your Sub-Zero
deaHer.
ModeHs 611,611G, 650 and 6BOG come with
a door stop pin to Himit the door swing to go
degrees. To instaHH the door stop pin for
ModeHs 611 and 650, remove the pin from the
pHastic package Hocated behind the grHHe and
insert it into the space provided on the top
hinge pilate. Tighten with a screwdriver. Refer
to iHHustration 22 bellow.
For ModeHs 611G and 650G, remove the
door stop pin from the pHastic package Hocated
behind the griHHe and insert it into the space
provided on the Hower hinge pilate. Tighten
with a screwdriver. Refer to iHHustration 23.
The importance of the instaHHation of the
Sub-Zero BuiHt-Hn unit cannot be overempha-
sized. Proper instaHHation is the responsibiHity
of the seHHingdeaHer or instaHHer.
IMPORTANT NOTE: To ensure a safe and
proper instaHHation, the foHHowing checkHist
shouHd be compHeted by the instaHHerto ensure
that no part of the instaHHation has been over-
Hooked.
Any questions or probHems about the instaHHa-
tion shouHd be directed to your Sub-Zero
deaHer or the Sub-Zero Customer Service
Department at 800-222-7820 or e-maiH
customerservice@subzero.com. You can aHso
visit our website at subzero.com.
