FRAMELESS CABINETRY
The illustrations show hypotheti-
cal installations of Integrated
base or tall units within frameless
cabinetry. Review, giving particu-
lar attention to the overall panel
specifications. Also refer to the
full-scale illustrations at the end
of this section for specifics on
door openings.
A
A
A
A) ALL REVEALS ARE 1/8" (3) *DIMENSIONS MAY VARY
SIDE VIEW
24"
(610)
PANEL WIDTH
45
3
/8"
(1153)
26
3
/4"* (679)
13
9
/16"
(345)
16
11
/16"*
(424)
4"*
(102)
80"*
(2032)
34
1
/ 2 "
(876)
*
27"
(686)
FINISHED OPENING
TOE KICK
79
7
/8"*
(2029)
A
A
A
A) ALL REVEALS ARE 1/8" (3) *DIMENSIONS MAY VARY
SIDE VIEW
24"
(610)
PANEL WIDTH
45
3
/8"
(1153)
35
3
/4"* (908)
13
9
/16"
(345)
16
11
/16"*
(424)
4"*
(102)
80"*
(2032)
34
1
/ 2 "
(876)
*
36"
(914)
FINISHED OPENING
TOE KICK
79
7
/8"*
(2029)
MODEL 736TC(I)
Installation of the
Model 736TC(I)
Integrated tall unit
within frameless
cabinetry.
*Dimensions may vary.
Dimensions are based
on a
1
/8" (3) reveal. A
reveal of up to
1
/4" (6)
is possible, but panel
dimensions need to be
adjusted accordingly.
27" (686)
WIDE MODELS
Installation of a
27" (686) wide
Integrated base or
tall unit within
frameless cabinetry.
*Dimensions may vary.
Dimensions are based
on a
1
/8" (3) reveal. A
reveal of up to
1
/4" (6)
is possible, but panel
dimensions need to be
adjusted accordingly.
