Sub-Zero 601R

29
Dimensions in parentheses are in
millimeters unless otherwise specified.
1
1
/
4
"
(32) PANEL
1"
(25) PANEL
*
1
/
4
"
(6) PANEL
1
/
2
"
(13) PANEL
3
/
4
"
(19) PANEL
130˚ DOOR OPENING
WITH 2" (51) FILLER STRIP
(TOP VIEW)
OPTIONAL
FRAMED EXTENDED
FULL-LENGTH HANDLE
STANDARD
FRAMED
FULL-LENGTH
HANDLE
DOOR CLOSED
DOOR OPEN @ 130˚
HINGE
2" (51)
FILLER STRIP
MAIN FRAME
ALLOW FOR FILLER LAP
BEHIND FLANGE
APPROX
PROFILE OF
STAINLESS
STEEL DOOR
AND HANDLE
OVERLAY PANEL
3/4" (19) THICK
(NOMINAL)
SUB-ZERO UNITSUB-ZERO UNIT
The full-scale illustration shows the
panel and handle profile for 130˚ door
opening with a 2" (51) filler strip.
Interference of door panels with
handles at maximum door swing may
require the use of an optional 90˚ door
stop available through your Sub-Zero
dealer.
PANEL AND HANDLE PROFILE – 130˚ DOOR OPENING
*Approximate thickness of wrapped
stainless steel door.
