Sub-Zero 632

48
1
8
3
4
MIN.
(3)
PANEL
SIDE MOLDING AND
INSTALLATION HARDWARE
PROVIDED BY SUB-ZERO
LINE OF INTERFERENCE
AT MAXIMUM DOOR OPENING
MOUNTING BRACKET SCREW
(19)
FLUSH
FURNITURE
FINISH
LINE OF INTERFERENCE
TO BACK
OF UNIT
24
(610)
SUB-ZERO DOOR
25
7
8
(657)
APPLIANCE DOOR WIDTH
34
7
8
(886)
FOR MODEL 736TC(I)
REVEAL
IMPORTANT NOTE: The depth of each
Integrated model is 24" (610) from the
front of the unit to its back. Your
design may necessitate moving the
unit back or cabinets forward to
achieve a flush fit.
FRAMED CABINETRY
DOOR CLOSED
Full-scale (top view)
24
(610)
LINE OF INTERFERENCE
SUB-ZERO
DOOR
TO BACK
OF UNIT
105˚ MAXIMUM
DOOR OPENING
1/4 scale (top view)
