Planning Information
Built-In Model 695
Dimensions in parentheses are in
millimeters unless otherwise specified.
14
2" (
51)
1" (25)
S
TAINLESS STEEL
H
ANDLE PROFILE
GLASSWELL PROFILE
R
EFRIGERATOR DOOR PROFILE – TOP VIEW
DOOR
NOTE: FOR OVERLAY APPLICATIONS, OPTIONAL STAINLESS STEEL HANDLE
MUST BE MOUNTED ON PANEL MINIMUM 5/8" (16) THICK.
HANDLE PLACEMENT
The full-scale illustration above shows proper
placement of the stainless steel handle for the
Model 695 refrigerator door in an overlay appli-
cation.
Adequate clearance is required under the handle
to assure proper access to the glasswell.
IMPOR
TANT NOTE:
F
or overlay applications,
the optional stainless steel handle must be
mounted on a panel at least
5
/8" (16) thick.
HANDLE PLACEMENT MODELS – OVERLAY APPLICATION
