Sealed System Information
Integrated (
Integrated (
700-
700-
2) Series
2) Series
4-6
#3756780 - Revision D - July, 2005
SEALED SYSTEM REFRIGERANT FLOW DIAGRAMS
Figure 4-7. Model 700TC/I-2 Refrigerant Flow
FREEZER COMPRESSOR
REFRIGERATOR COMPRESSOR
REFRIGERATOR EVAPORATOR
FREEZER EVAPORATOR
CONDENSER
(FRONT - FREEZER)
(BACK - REFRIGERATOR)
FREEZER HEAT-EXCHANGER
FREEZER FILTER-DRIER
REFRIGERATOR HEAT-EXCHANGER
FRAME HEATER (HOT GAS)
REFRIGERATOR FILTER-DRIER
= REFRIGERATOR SEALED SYSTEM
= FREEZER SEALED SYSTEM
