Sub-Zero BI-36UFD - Page 5

Extended Height Grille 5
subzero.com/specs
FUNCTIONAL
PANEL
INSTALL PANEL
A
1
/4" (6) thick functional panel must be installed in the
inner grille frame (the part that flips up) to prevent warm
air discharge from short-circuiting back into the system.
Use sizing for the ‘backer panel’ found in the panel
configurator or Sub-Zero design guide.
Air Flow Requirements
SIDE VIEW
