INTEGRATED REFRIGERATION
Custom Panels
For model IC-36FI, a custom door panel and handle hard-
ware must be provided. Refer to the panel requirements
chart and typical panel dimensions.
The thickness of the custom panel can vary. A minimum
5
/8" (16) thick panel is required, but the thickness can be
increased provided it does not exceed the weight limit. The
depth of model IC-36FI is 24"
(610). Allow for panel thick-
ness when planning the nished opening depth. Refer to the
full-scale template at the end of this guide.
CAUTION
As reveals between cabinetry and the unit decrease,
severe nger pinching can occur while door is closing.
Finish all sides of the custom panel. They will be visible
when the door is open.
D-style handles are recommended. Door handles must be
located near the edge of the panel opposite the hinge and
should be centered top to bottom. Stainless steel tubular
and pro handles are avail able through an authorized
Sub-Zero dealer. For local dealer information, visit the nd a
showroom section of our website, subzero.com.
PANEL REQUIREMENTS
PANEL WEIGHT MAX
IC-36FI 75 lb (34 kg)
PANEL THICKNESS MIN
IC-36FI
5
/8" (16)
TYPICAL PANEL DIMENSIONS
Typical panel dimensions are based on an 84" (2134) nished
height with a 4"
(102) toe kick and
1
/8" (3) reveals. Panel
dimensions must be adjusted accordingly for all other instal-
lations. Refer to the illustration for panel height and the chart
below for panel width.
PANEL WIDTH
MODEL W
IC-36FI 35
3
/4" (908)
DUAL INSTALLATION
For dual installations, refer to the illustration for panel height
and the chart below for panel width.
PANEL WIDTH
MODEL W
IC-36FI 35
13
/16" (910)
W
49
3
/8"
(1254)
13
9
/16"
(345)
16
11
/16"
(424)
W
W
79
7
/8"
(2029)
Model IC-36FI
