32
|
English
PRO 48 REFRIGERATION
H
OPENING
HEIGHT
FRONT VIEW
VIEW
W
OPENING WIDTH
D
OPENING
DEPTH
TOP VIEW
Opening Dimensions
STANDARD AND FLUSH INSTALLATION
For standard built-in installations, the face frame of the unit
will extend 51 mm beyond cabinetry. For ush installations,
the front of the face frame will be ush with surrounding
cabinetry.
OPENING DIMENSIONS
INSTALLATION W H D
Standard 1206 mm 2127 mm 610 mm
Flush 1219 mm 2137 mm 660 mm
WINE INTEGRATED PRO 48 BUILT-IN
