Sub-Zero ID-24FI Design Guide

8 | Sub-Zero Customer Care 800.222.7820
INTEGRATED REFRIGERATION
Custom Panels
For integrated models, custom door panels and handle
hardware must be provided. Refer to the panel requirements
chart and typical panel dimensions.
The thickness of the custom panel can vary. A minimum
5
/8" (16) thick panel is required, but the thickness can be
increased provided it does not exceed the weight limit. The
depth of each integrated model is 24"
(610). Allow for panel
thickness when planning the nished opening depth. Refer
to the full-scale template on page 11.
CAUTION
As reveals between cabinetry and the unit decrease,
severe nger pinching can occur while door is closing.
Finish all sides of custom panels. They will be visible when
the door/drawer is open.
D-style handles are recommended. Door handles must be
located near the edge of the panel opposite the hinge and
should be centered top to bottom. Drawer handles must
be located near the top edge of each panel. Stainless steel
tubular and pro handles are avail able through an authorized
Sub-Zero dealer. For local dealer information, visit the nd a
showroom section of our website, subzero.com.
PANEL REQUIREMENTS
PANEL WEIGHT MAX
18" Column 45 lb (20 kg)
24" Column 60 lb (27 kg)
30" Column 75 lb (34 kg)
36" Column 75 lb (34 kg)
PANEL WEIGHT MAX
30" Tall (door) 50 lb (22 kg)
36" Tall (door) 60 lb (27 kg)
Drawer 15 lb (7 kg)
PANEL THICKNESS MIN
All Panels
5
/8" (16)
TYPICAL PANEL DIMENSIONS
Typical panel dimensions are based on an 84" (2134) nished
height for column and tall models and 34
1
/2" (876) for drawer
models, with a 4"
(102) toe kick and
1
/8" (3) reveals. Panel
dimensions must be adjusted accordingly for all other instal-
lations. Refer to the illustration for panel heights and the
chart below for panel widths.
PANEL WIDTH
MODEL W
18" Model 17
3
/4" (451)
24" Model 23
3
/4" (603)
27" Model 26
3
/4" (679)
30" Model 29
3
/4" (756)
36" Model 35
3
/4" (908)
DUAL INSTALLATION
For dual installations, refer to the illustration for panel
heights and the chart below for panel widths.
PANEL WIDTH
MODEL W
18" Model 17
13
/16" (452)
24" Model 23
13
/16" (605)
27" Model 26
13
/16" (681)
30" Model 29
13
/16" (757)
36" Model 35
13
/16" (910)
W
49
3
/8"
(1254)
13
9
/16"
(345)
16
11
/16"
(424)
WW
79
7
/8"
(2029)
Column Tall Drawer

Sub-Zero ID-24FI Specifications

General

Color	custom, custom panel ready
Total Capacity	3.8 cubic feet
Freezer Capacity	3.8 cubic feet
Defrost System	automatic
Temperature Control	electronic
Ice Maker	yes
Smart Home	yes
Wi-Fi	wi-fi
Annual Energy Consumption	377 kilowatt hours
Voltage	115 volts
Current	15 amperes

Weight and Dimensions

Depth	24 inches
Height	34 1/2 inches
Width	24 inches
Net Weight	170 pounds
