STORAGE
DRAWER REMOVAL
To remove, pull the storage drawer forward until it stops.
Lift the front of the drawer slightly and pull straight out. To
reinstall, place drawer onto the slides, then align the holes at
the front of the drawer with the pegs on the slides. Refer to
the illustration below.
For model 427RG, the upper drawer has a control cable that
must be disconnected before removing the drawer. Refer to
the illustration below.
Storage Drawers
DRAWER DIVIDER
To remove the divider, pull it forward and release the back
edge from notches in the drawer. Lift up and out. Reverse to
reinstall. Refer to the illustration below.
Drawer divider.
Storage drawer removal.
Control cable (model 427RG).
