Subaru 1998 Forester - Combination Meter Overview

FORESTER NA. (E)
3-4
Combination meter overview
HS0007
1 ABS warning light (page
3-12)
2 Speedometer (page 3-5)
3 Turn signal indicator light
(page 3-13)
4 Tachometer (page 3-6)
5 AT oil temperature warning
light (page 3-12)
6 High beam indicator light
(page 3-13)
7 SRS AIRBAG warning light
(page 3-8)
8 Door opening warning light
(page 3-13)
9 Temperature gauge
(page 3-7)
Q CHECK ENGINE warning
light/Malfunction indicator
lamp (page 3-10)
W Front-wheel drive warning
light (page 3-13)
E Charge warning light (page
3-9)
R Brake system warning lights
(page 3-9)
T Oil pressure warning light
(page 3-9)
Y Odometer/Trip meter
selection and trip meter reset
knob (page 3-5)
U Odometer/Trip meter
(page 3-5)
I Seat belt warning light
(page 3-8)
O Low fuel warning light
(page 3-7)
P Fuel gauge (page 3-6)
8
PO I UY
T
EWQ 9R
1 2 3 4 5
6 7
