FORESTER (72F) NA (E) A8040B
11-52
the fender.
3. Remove the bulb holder from the front turn signal light assembly by
turning it counterclockwise.
4. Pull the bulb out of the socket. Install a new bulb.
5. Set the bulb holder into the front turn signal light assembly and turn it
clockwise until it locks.
6. Set the front turn signal light assembly into the fender. Tighten the
mounting screw.
J Rear combination lights
B Brake/tail and rear turn signal light
HS0219HS0218
1. Unlatch the rear combination light cover by pulling the knob. Open
the cover up.
2. Remove the bulb holder from the rear combination light assembly
by turning it counterclockwise.
3. Remove the bulb from the socket by pushing it and turning coun-
terclockwise. Install a new bulb.
4. Set the bulb holder into the rear combination light assembly and
turn it clockwise until it locks.
5. Close the cover and latch the lock.
