FORESTER (72F) NA (E) A8040B
12
Specifications
12-5
– CONTINUED –
Fuse panel CircuitFuse rating
11 15A D Engine ignition system
D SRS airbag
12 10A D Illumination brightness control
13 15A D Wiper deicer
14 Empty
15 20A D Windshield wiper and washer
D Rear window wiper and washer
16 20A D Brake light
17 15A D Air conditioner
18 15A D Backup light
D Cruise control
D ABS control
19 20A D Rear accessory power socket
D Seat heater
