IMPREZA U.S.A. (E) A1820BE–A
10-34
HS0194HS0193
Stopper
6. Install the wiper blade assembly to the wiper arm. Make sure that it
locks in place.
7. Lower the wiper arm.
Brake pedal
Check the brake pedal free play and reserve distance according to the
maintenance schedule in the “Warranty and Maintenance Booklet”.
B Checking the brake pedal free play
OM-H0224
0.04 — 0.12 in
(1.0 — 3.0 mm)
Stop the engine and firmly depress the brake pedal several times.
Lightly press the brake pedal down with one finger to check the free
play with a force of less than 10 N (2 lb., 1 kg).
If the free play is not within proper specification, contact your
