IMPREZA U.S.A. (E) A1820BE–A
10
Maintenance and service
10-49
– CONTINUED –
4. Disconnect the connector behind the case cap.
5. Release the retainer spring.
6. Replace the bulb with a new one. Then reconnect the connectors
and reinstall the removed parts in the reverse order of removal.
B Type B
HG0326HG0325
1. Remove the front fog light cover.
2. Remove the front fog light assembly by removing the two bolts.
3. Disconnect the connector.
4. Remove the front fog light case cap by turning it counterclockwise.
HG0327
Spring
Connector
5. Disconnect the connector behind the case cap.
6. Release the retainer spring.
7. Replace the bulb with a new one. Then reconnect the connectors
and reinstall the removed parts in the reverse order of removal.
To Next Page
