11-79
Maintenance and service
– CONTINUED –
1) Backup light
2) Rear turn signal light
3) Brake/tail light
4) Tail light
5) Brake light
2. Open the rear portion of the side trunk trim panel.
3. Remove the bulb holder from the rear combination
light assembly by turning it counterclockwise.
4. Remove the bulb from the socket by pushing it and
turning counterclockwise. Install a new bulb.
5. Set the bulb holder into the rear combination light
assembly and turn it clockwise until it locks.
6. Secure the rear trunk trim panel with the clips.
T Wagon
1. Using a Phillips screwdriver, remove the upper and
lower screws that secure the side cover of the rear
combination light assembly.
5
54
2
3
1
UGB539BB
UGB540BA
