120
1-7. Safety information
BRZ_U
SRS airbag system monitors
A diagnostic system continually
monitors the readiness of the
SRS airbag system (including
front seatbelt pretensioners)
while the vehicle is being driven.
The SRS airbag system warning
light will show normal system
operation by illuminating for
approximately 6 seconds when
the ignition switch is turned to
the “ONposition.
The following components are monitored by the indicator:
Front sub sensor (right-hand side)
Front sub sensor (left-hand side)
Airbag control module (including impact sensors)
Frontal airbag module (driver’s side)
Frontal airbag module (front passenger’s side)
Side airbag sensor (center pillar right-hand side)
Side airbag sensor (center pillar left-hand side)
Door impact sensor (right-hand side)
Door impact sensor (left-hand side)
Side airbag module (driver’s side)
Side airbag module (front passenger’s side)
Curtain airbag sensor (rear wheel house right-hand side)
Curtain airbag sensor (rear wheel house left-hand side)
Curtain airbag module (right side)
