12-6 Specifications
14 15A y Position light
y Tail light
y Rear combination light
15 20A y Console socket
16 10A y Illumination
17 15A y Seat heaters
18 10A y Backup light
19 7.5A y Headlight right side relay
20 Empty
21 7.5A y Starter relay
22 15A y Air conditioner
y Rear window defogger relay coil
23 15A y Rear wiper
y Rear window washer
24 15A y Audio unit
25 15A y SRS airbag system (Main)
26 7.5A y Power window relay
27 15A y Rear blower fan
28 15A y Rear blower fan
29 15A y Fog light
Fuse panel Fuse rating Circuit
30 30A y Front wiper
31 7.5A y Auto air conditioner unit
y Integrated unit
32 7.5A y Headlight left side relay
33 7.5A y Vehicle dynamics control unit
Fuse panel Fuse rating Circuit
