Subaru ascent - Combination Meter Display (Color LCD)

12
◆
Some functions are available on certain models.
◆
For detailed operating and safety information, please refer to your Owner’s Manual.
1
Clock
2
Outside temperature
3
Information screen
Control switch: Press the ENTER or
button on
the instrument panel to switch the item
displayed on the basic screen. You
can operate the items on the setting
screen by using the ▲, ▼and ENTER
or buttons.
Color LCD (if equipped)
1
Eco gauge
2
Warning screen/Basic screen
3
EyeSight screen
4
Telltale screen
5
Select lever/gear position indicator
6
X-MODE indicator
7
Odometer/double trip meter
Control switch: By operating ▲ or ▼ of the control
switch, the screens and selection
items can be switched. When the
/
SET switch is pulled toward you, the
item can be selected and set.
Combination meter display (color LCD)
D
Control switch
1
3
2
1
2
3
4
Control
switch
Deactivating
the Eyesight
system
Activating
the EyeSight
system
Front view
monitor models
Other models
65 7 65 7
