23
-
CLEANING AND ADJUSTING
SPARK PLUG
(a) If the plug is contaminated with carbon,
remove it using a plug cleaner or wire
brush.
(b) Adjust the electrode gap to
0.6 to 0.7 mm.
Spark plug :
SGX3500
TORCH E6RC
(NGK BR-6HS)
SGX5000
SGX7500
NGK BR-6HS
Gap 0.6 to 0.7 mm
(
0.024 to 0.028 in.
)
CLEANING FUEL STRAINER
Dirt and water in the fuel are removed by
the fuel strainer.
(a) Remove the strainer cup and throw
away water and dirt.
(b) Clean the screen and strainer cup with
gasoline.
(c) Tightly fasten the cup to main body,
making sure to avoid fuel leak.
