CONTROL PANEL
[Electric starter model]
Key switch
( SGX3500 )
(SGX7500)
(
SGX5000 )
Hour meter
Hour meter
Hour meter
AC receptacle
20A (MAX 13A)
AC receptacle
20A (MAX 19A)
AC receptacle
20A (MAX 19A)
AC receptacle
20A (MAX 20A)
AC receptacle 20A (MAX 13A)
Earth
(
ground)
terminal
Earth
(
ground)
terminal
Earth
(
ground)
terminal
AC circuit
breaker
AC circuit
breaker
AC receptacle
30A (MAX 28A)
AC circuit
breaker
AC circuit
breaker
Oil warning
lamp
