5. Open manual shut-off valve (if so equipped) or the valve at the outside LP
tank. Correct operating characteristics depend on the valve being positioned
fully open. Never attempt to operate with a valve partially closed. NOTE: This
furnace
is
equipped with a valve shut-off switch with switch
in
' OFF" position.
Gas
will not flow to burner nor will the furnace operate.
6.
Set thermostat lever to desired setting. If set above room temperature, blower
will
come on.
7.
Allow 30 seconds for main burner to light after blower comes
on
. This furnace
is
equipped with an ignition device which automatically lights the burner. Do
not try to
light the burner
by
hand.
8.
If burner does not light, repeat Steps 1 through 8.
9.
If after three (3) attempts with no ignition, go to shut down and contact your
dealer or a local recreational vehicle service agency.
Do
not continue to cycle
furnace through thermostat in
an
attempt to get ignition. NOTE: If furnace
should lock out, the blower will go off in 5 minutes and remain
off
until unit
is
reset
by
reactivating thermostat.
TO
SHUTDOWN
1. Set the thermostat to lowest setting, then move lever to ' OFF" position.
2.
Turn manual shut off valve (if so equipped) to the 'OFF" position.
Do
not force.
ELECTRODE
AD
J
USTMENT
For consistent ignition
of
the burner, it
is
impo
rt
ant that the electrode be positioned
properly over the top of the burner. The electrode was set at the factory for proper
ignition and
should not need further adjustmen
t;
however, if you should experience
inconsistent ignition, reposition
electrode as
fo
ll
ows:
Equipment
needed: flashlight, black felt-tip
pen
, needle-nose pliers, measuring tape
NOTE: Furnace must
be
removed. (See instructions for removing unit.)
1.
Remove burner from combustion chamber by removing six (6) screws which
attach the burner to the chamber and air
baffles (plates
).
2.
Locate the lance
in
relation to the burner ports for electrode positioning
by
:
a.
Shine a flashlight into the burner venturi as illustrated. (Be sure flashlight
lens
is against the end of the burner.)
b. Light
will reflect off the lance in the venturi
of
the burner and
sh
ine through
a portion
of
the two (2) rolls
of
burner ports
in
the top of the burner.
c.
Using a black felt-tip pen, mark a line along top
of
burner 3/16'
in
back of
the
lance and parallel with lance. Make
an
additional mark indicating the
center
line of the lance. (See illustration
.)
Both marks will
be
used later as
reference marks; therefore, keep
lines thin .
3.
Reassemble the burner.
4.
Adjust electrode so the electrode probe
is
positioned along the marked center
line of the burner lance and the tip
of
the electrode terminates 3/16" from the
back
of
the lance. (At the line marked in Step 2-c.) (See Figure 5.)
5.
IMPORTANT:
Be
sure
electrode
probe
maintains
a 1/8"
spark
gap
over
the
burner
as
illustrated.
6.
Reinstall the furnace into the cabinet followi
ng
the instructions
in
the manual.
PARTS
AND
SERVICE
Contact a conveniently located recommended Suburban Service Center.
Describe to them the nature of your
problem, make an appointment, if necessary,
and provide for
delivery of your RV with the appliance installed.
To obtain information on locati
ng
a local service agency, contact:
AIRXCEL, Inc.,
Suburban
Division
Customer Service Department
676 Broadway
Street
Dayton, TN 37321
(423) 775-2131 Ext.
7101
www.RVComfort.com
5
