11
DIP SWITCHES
VOX
When a speaking into a microphone connected to
the MIC1 channel the VOX function will lower the
volume of the input channels by -40dB, and return
them to normal when speaking has stopped.
PHANTOM
Use this switch to provide +24V phantom power to
condenser microphones.
MIC3/LINE1
Use this switch to change the sensitivity of channel
MIC3/LINE1 between MIC and LINE levels.
MIC4/LINE2
Use this switch to change the sensitivity of channel
MIC4/LINE2 between MIC and LINE levels.
Note: Ensure the amplifier is switched off before
making any changes to the DIP switches.
Making any changes when the amplifier is
switched on may cause loud noises which
can damage the speakers
MIC 4 / LINE 2
MIC 3 / LINE 1
PHANTOM
VOX
MIC
LINE
OFF
ON
