Subzero MINICONTROL User Manual

OVERVIEW
1. CONTROL MESSAGE BUTTON
Transmits the control message CC64. This button
is not editable.
2. PROGRAM CHANGE DIAL
Adjusts the program change message. This dial is
not editable.
3. CONTROL MESSAGE BUTTON
Transmits the control message CC67. This button
is not editable.
4. CHANNEL DIAL
Transmits the control change message to the
selected function in your DAW software.
5. CHANNEL FADER
Transmits the control change message to the
selected function in your DAW software.
6. USB CONNECTION
Connect the supplied USB cable here.
7. VOLUME FADER
Adjusts the master volume. This button is not
editable.
8. BANK SELECT BUTTON
Selects the settings bank currently used. The
bank settings can be changed using the Software
Editor.
9. BANK LED
Displays which bank is currently being used.
10. ASSIGNABLE BUTTON 1
Assign a number of different functions to this
button. The function can be assigned using the
Software Editor.
11. ASSIGNABLE BUTTON 2
Assign a number of different functions to this
button. The function can be assigned using the
Software Editor.
12. CHANNEL BUTTON
Transmits the control change message to the
selected function in your DAW software.
13. LOOP
Activates (lit) or deactivates (unlit) the loop
function of your DAW software.
14. REWIND
Rewinds through the current project in your
DAW software.
15. FAST FORWARD
Fast forwards through the current project in your
DAW software.
16. STOP
Stops the current project in your DAW software.
17. PLAY
Plays the current project in your DAW software.
18. RECORD
Activates (lit) or deactivates (unlit) the record
function of your DAW software.
EDIT
OCTAVE
MOD
PITCH – PITCH +
A
1 2 3 4 5 6 7 8 V
B
MIN MAX MIN MAX MIN MAX MIN MAX MIN MAX MIN MAX MIN MAX MIN MAX MIN MAX
BANK
1 2 3 4
X
Y
1 2 3 4
BANK
PAD 1 PAD 2 PAD 3 PAD 4 PAD 5 PAD 6
PAD 7 PAD 8 PAD 9 PAD 10 PAD 11 PAD 12
5
1
7
8
2 3 4 5
9 10 11 13 14 15 16 17 18
6
12
