10
APPLICATION
The SZPA-P88/P810 can be used in a wide
variety of sound reinforcement applications,
from a full-band performance onstage to solo
street performances. This is a powerful,
high-performance system in an exceptionally
compact and portable package.
Connect a microphone to the XLR connectors
(channels 1 to 4), connect a bass and guitar to the
input jacks (3 and 4) and connect a keyboard to the
stereo input jacks (channels 5/6 to 7/8).
If you have a powered speaker, you can connect
it to the MONITOR OUT jack for monitoring your
vocals. For optimum results in band performance
applications and to create a more powerful sound
for music, make sure to set the SPEECH/MUSIC
switch to MUSIC.
NOTE:
For best results when connecting an electric
guitar or bass guitar to the mixer, use a direct box,
preamp (guitar amp), or amp simulator.
