Subzero SZPA-P810 - SPECIFICATIONS

12
SPECIFICATIONS
MIXER SZPA-P88 SZPA-P810
MONO inputs (4) 2x LINE/MIC IN (XLR) + 2x LINE MIC IN (COMBO) (4) 2x LINE/MIC IN (XLRJ + 2x LINE/MIC IN (COMBO)
STEREO inputs (2) 1x LINE IN (2x JACK)+ 1x LINE IN (1 x AUX JACK
2x RCA)
(2) 1x LINE IN (2x JACK)+ 1x LINE IN (1 x AUX JACK
2x RCA)
EQ HIGH l0KHz (±15dB ), LOW l00Hz (±l5dB) HIGH l0KHz (±15dB ), LOW l00Hz (±15dB)
PHANTOM power +15V CH1-2 +15V CH1-2
Internal Effect REVERB (CH1-4) REVERB (CH1-4)
Outputs MONITOR OUT (2x JACK), SUB OUT (1x JACK) MONITOR OUT (2x JACK), SUB OUT (1x JACK)
SPEAKER OUT (2x JACK) SPEAKER OUT (2x JACK)
Main EQ SPEECH/MUSIC selector SPEECH/MUSIC selector
Metering 6 LED VU-meter 6 LED VU-meter
MULTIMEDIA
Player Type Bluetooth/USB Bluetooth/USB
Compatible File Formats WAV, MP3, WMA WAV, MP3, WMA
AMPLIFIER
AmplifierType CLASS D with SMPS CLASS D with SMPS
RMS Power 2x150W @4Ω (1KHz, 1% THD) 2x150W @4Ω (1KHz, 1% THD)
Frequency Response MUSIC: 20Hz - 20KHz, SPEECH: 80Hz - 20KHz MUSIC: 20Hz - 20KHz, SPEECH: 80Hz - 20KHz
LOUDSPEAKER
Loudspeaker System 2-way system vented 2-way system vented
High Frequency Device 1" compression driver 1" VC-horn loaded 1" compression driver 1" VC-horn loaded
Low Frequency Device 8" woofer with 2" VC l0” woofer with 2" VC
Angular Coverage T90° Hx60" V T90° Hx60” V
Impedance 4Ω 4Ω
Frequency Response 70Hz - 20KHz, (±10dB) 65Hz - 20KHz, (±10dB)
Construction Black Polypropylene, Metal Grille Black Polypropylene, Metal Grille
Handles 1 top 1 top
Pole Holder 1 bottom 1 bottom
GENERAL
Dimensions (W x H x D) SPEAKER: 28 x 45.7 x 25.4cm SPEAKER: 32 x 50 x 29cm
MIXER: 18 x 32 x 9 cm MIXER: 18 x 32 x 9cm
Weight SYSTEM: 20kg SYSTEM: 25kg
SPEAKER: 8.6kg SPEAKER: 10.6kg
MIXER: 2.4kg MIXER: 2.4 kg
Power Supply 220-240V~50/60Hz 220-240V~50/60Hz
Power Consumption 600W 600W
