Sullair MCH-2RD - Bolt, Handle

MCH-4RD/BALL (68252242-004)
MCH-4HX/BALL (68252245-004)
ILLUS
NO.
PART NUMBER DESCRIPTION QTY.
1 68723229 SLEEVE, RETAINER 1
2 68524725 BALL 6
3 250021-223 MCH RETAINER (TAPERED) BODY 1
4 68722452 DEFLECTOR, MCH-4 1
5 68 VE 8120 NYLOC NUT, HANDLE BOLT 4
6 68722428 SPACER, HANDLE BOLT (STEEL) 4
7 68722759 BUSHING, 0.580" HEX - USE ON MCH-4HX/BALL (68252245-004) 1
8 68722307 CYLINDER-4" 1
9 68524063 DOWEL, PIN 2
10 68722229 VALVE DISC 1
11 68524308 O-RING 1
12 68723119 BUSHING, THROTTLE VALVE 1
13 68722225 SPRING, THROTTLE VALVE 1
14 68 CJ 0018 O-RING 1
15 68722224 BUSHING, AIR INLET 3/8 NPT 1
16 68722274 BUSHING, AIR INLET 7/8-24 1
17 68723118 VALVE, THROTTLE 1
18 68524155 BOLT, HANDLE 4
19 68723013 PIN 2
20 68723115 HANDLE, BARE 1
21 68722228 TRIGGER 1
22 68722230 CHEST, VALVE 1
23 68722231 BUMPER, VALVE CHEST 1
24 68722308 PISTON-4" 1
25 68723240 BUSHING, 0.680" ROUND - USE ON MCH-4RD/BALL (68252242-004) 1
26 68723120 RING, ABSORBER 1
27 68722232 FLANGE, CYLINDER 1
28 68722427 SPACER, VIBRATION 4
29 250012-530 SPRING, RETAINER LOCK 1
30 68723237 SPRING, RETAINER 1
.31 68524726 RETAINING RING 1
MCH-4/BALL
33
02250218-225 R02
©
2015 Sullair, LLC.
Update: September 12 2015 Subject to EAR, ECCN EAR99 and related export control restrictions.
