Why is my Sulzer Water Pump switching on and off intermittently?
Your Sulzer Water Pump might be intermittently switching on and off due to several reasons: * The temperature sensor could be shutting down the pump. The motor will restart automatically once the pump cools down. * There may be an impeller blockage, so check the impeller. * Check thermal relay settings in the control panel.
What to do if my Sulzer Water Pump does not operate?
If your Sulzer Water Pump isn't operating, here are a few potential causes and solutions: * **Leakage sensor shutdown:** Check for a loose or damaged oil plug, or locate and replace a faulty mechanical seal or damaged o-rings. * **Air lock in volute:** Shake or raise and lower the pump repeatedly until air bubbles no longer appear at the surface. * **Level control override:** Check for a float switch that is faulty or tangled and held in the OFF position in the sump. * **Impeller jammed:** Inspect and remove any jammed objects. Check the gap between the impeller and the bottom plate, and adjust if necessary. * **Gate valve closed or non-return valve blocked:** Open the gate valve and clean any blockage from the non-return valve.
Why does my Sulzer Water Pump have excessive noise or vibration?
Excessive noise or vibration in your Sulzer Water Pump could be due to: * A defective bearing, which would require replacement. * A clogged impeller. Remove and clean the hydraulics. * The wrong direction of rotation. Change the rotation by interchanging two phases of the power supply cable.
How to fix low head or flow in my Sulzer Water Pump?
If you're experiencing low head or flow with your Sulzer Water Pump, consider these potential solutions: * **Wrong direction of rotation:** Change the rotation by interchanging two phases of the power supply cable. * **Gap too wide between impeller and bottom plate:** Reduce the gap. * **Gate valve partially open:** Open the valve fully.
General| Brand | Sulzer |
|---|---|
| Model | AS 0530 |
| Category | Water Pump |
| Language | English |
Defines the purpose and suitable applications for the AS series submersible wastewater pumps.
Explains the coding system used for identifying different pump models and their features.
Details the mandatory personal protective equipment (PPE) required for safe handling and operation.
Lists the electrical safety approvals for the AS series pumps.
Details the specific certifications for explosion-proof motors used in hazardous environments.
Provides essential information and precautions for operating pumps in hazardous areas.
Specifies special conditions and requirements for the safe operation of S-type explosion-proof motors.
Defines requirements for operating explosion-proof pumps when installed in wet wells.
Explains how to read and record information from the pump's nameplate for reference.
Provides weight details for AS pumps operating at 50 Hz.
Provides weight details for AS pumps operating at 60 Hz.
Specifies the weight of lifting chains compliant with EN 818 standard.
Details safe practices and equipment requirements for lifting the pump units.
Provides guidelines for ensuring the pump's safety and integrity during transportation.
Outlines recommended procedures for storing the pumps to maintain their condition.
Explains how to protect the motor connection cable from moisture during storage or installation.
Describes the requirements and procedures for equipotential bonding in pump installations.
Details the regulations and best practices for installing the pump's discharge line.
Covers different methods and configurations for installing the AS pumps.
Explains the process of installing the pump in a submerged concrete sump setup.
Provides instructions for installing the pump in a dry-installed configuration.
Details the setup for transportable installations using a skirtbase.
Explains how to vent the pump's volute to prevent air locks and ensure proper operation.
Describes the optional leakage sensor (DI) for monitoring the motor and seal chambers.
Explains the function and integration of thermal sensors for motor overheat protection.
Details the operation and specifications of bimetallic temperature sensors.
Illustrates typical wiring configurations for three-phase and single-phase pump connections.
Defines the recommended operating modes and starting frequencies for the AS pumps.
Outlines the procedure for verifying the correct rotational direction of the pump motor.
Explains how to alter the pump's direction of rotation if it is incorrect.
Offers general advice and recommendations for maintaining the reliability of AS pumps.
Details the process for filling and changing the lubricating oil in the motor chamber.
Provides a table listing the required oil volumes for different pump and motor types.
Explains how to adjust the Contrablock bottom plate clearance for optimal performance.
Guides users on how to reset the clearance gap after wear has occurred.
Discusses the pump's bearings and mechanical seals, and their replacement.
Details the procedure and safety requirements for replacing the pump's power cable.
Provides instructions for operators and service personnel on how to clear pump blockages.
Steps for operators to attempt clearing blockages via control panel reset buttons.
Detailed procedures for service personnel to clear pump blockages.
Recommends cleaning procedures for transportable and fixed installations.
