Sumake ES-BS1002 - Page 15

PARTS LIST
No. Parts No. Descri
p
tion Q't
y
No. Parts No. Descri
p
tion Q't
y
1 EPCJ20012-3 Suspension Hook 1 26 EPGK21181 "C" Ring 1
EPCBB00012 Housing-Underside 1 27 EPGI21191 Iron Washe
r
1
EPCBB00012-1 Housing-Underside (ESD) 1 EPGH21221-2 Planet Gear For ES-BS1002, ES-BS1003 3
EPCI50212-19 Forward/Reverse Lever For ES-BS1002 1 EPGH92260 Planet Gear For ES-BS1004 3
EPCI50212-17 Forward/Reverse Lever For ES-BS1003 1 EPGG21231 Gear Seat For ES-BS1002, ES-BS1003 1
EPCI50212-18 Forward/Reverse Lever For ES-BS1004 1 EPGG92287 Gear Seat For ES-BS1004 1
4 EPC50220-1 Led Light Cover (Limpid) 2 EPG20104-1 Central Gear For ES-BS1002, ES-BS1003 1
5 EPEG31438-8 Indication Light P.C.B. 1 EPG20122 Central Gear For ES-BS1004 1
6 EPEG31504-11 Power Module 1 EPGH21221-2 Planet Gear For ES-BS1002, ES-BS1003 3
7 EPE33304-2 Buzze
r
1 EPGH92260-1 Planet Gear For ES-BS1004 3
8 EPEG31452-2 P.C.B. 1 EPGG21516 Gear Seat For ES-BS1002, ES-BS1003 1
9 EPW50119-1 PC Board Gap Column 4 EPGG92287-1 Gear Seat For ES-BS1004 1
EPEG31452-1-4 P.C.B. For ES-BS1002, ES-BS1003 1 EPGA81104 Gear Case For ES-BS1002, ES-BS1003 1
EPEG31452-1-5 P.C.B. For ES-BS1004 1 EPGA81104-1 Gear Case For ES-BS1004 1
11 EPCH90141-1 Screw 4 34 EPGN21251 Bearing 1
EPCC50022 Trigger Assembly 1 EPGC90308-1 Cam For ES-BS1002, ES-BS1003 1
EPCC50022-1 Trigger Assembly (ESD) 1 EPGC90308-2 Cam For ES-BS1004 1
13 EPCK28031-1 Trigger Spring 1 36 EPGP30361 Steel Balls 5mm 3
14 EPEG31420-28 Brake P.C.B. 1 EPGD91419
A
Shaft For Hex. 5mm Type (Opt.) 1
15 EPCI50217-5 Brake Leve
r
1 EPGD91419 Shaft For Hex. 6.35mm Type (Opt.) 1
16 EPC40407-1 Spring 1 EPGD91419-1 Shaft For Hex. 6.35mm-B9.5 Type 1
17 EPCH20504-14 Screw 1 EPGP21291
A
Steel Balls For Hex. 5mm Type (Opt.) 2
18 EPCJ20014-1 Waist Hook 1 EPGP21291B Steel Balls For Hex. 6.35mm Type 2
19 EPCH20527 Screw 6 39 EPGF90328 Waring Plate 1
EPCAB00012 Housing-Upside 1 EPGE92424 Waring Spring For ES-BS1002 1
EPCAB00012-1 Housing-Upside (ESD) 1 EPGE92423 Waring Spring For ES-BS1003 1
21 EPE30180-1 Resistance NTC 1 EPGE92422 Waring Spring For ES-BS1004 1
22 EPCH20504-11 Motor Screw 7 41 EPGY21321 Waring Spring Base 1
EPMO00017-1CE Motor Assembly For ES-BS1002, ES-BS1003 1 42 EPGN30434 Bearing 1
EPMO00017-2CE Motor Assembly For ES-BS1004 1 43 EPG21305-5 Washe
r
1
24 EPM11317-1 Drive Pinion For ES-BS1002, ES-BS1003 1 44 EPG20213 Clutch Case 1
EPGZPTA2000-1
A
Gear Housing For ES-BS1002 Hex. 5mm (Opt.) 1 45 EPGL21371 Torque Adjust Pin 4
EPGZPTA2000-1B Gear Housing For ES-BS1002 Hex. 6.35mm (Opt.) 1 46 EPGM21381 Torque Adjust Ring 1
EPGZPTA2000-2B Gear Housing For ES-BS1002 Hex. 6.35mm-B9.5 1 47 EPGS21391 "C" Ring 1
EPGZPTA3000-1
A
Gear Housing For ES-BS1003 Hex. 5mm (Opt.) 1 48 EPGJ21352 Bit Sleeve 1
EPGZPTA3000-1B Gear Housing For ES-BS1003 Hex. 6.35mm (Opt.) 1 49 EPGO21346 Bit Spring 1
EPGZPTA3000-2B Gear Housing For ES-BS1003 Hex. 6.35mm-B9.5 1 50 EPG21435 Washe
r
1
EPGZPTA4500-1
A
Gear Housing For ES-BS1004 Hex. 5mm (Opt.) 1 51 EPGQ21361 "C" Ring 1
EPGZPTA4500-1B Gear Housing For ES-BS1004 Hex. 6.35mm (Opt.) 1 52 EPCD91041 Couple
r
1
EPGZPTA4500-2B Gear Housing For ES-BS1004 Hex. 6.35mm-B9.5 1 53 EPP11020-7 Insulating Washer (ESD) 8
ES-BS1002(3)(4)-P-2303C-K2
ES-BS1002(3)(4) BRUSHLESS FULL AUTO SHUT-OFF CORDLESS SCREWDRIVER
