STANDARDISED GEAR UNITS FOR
COOLING TOWER DRIVES
PROGRAMME - SELECTION
800
710
630
560
500
400
355
315
280
250
225
200
160
132
110
90
75
55
45
37
30
22
18,5
3,55 4 4,5 5 5,6 6,3 7,1 8 9 10 11,2 12,5 14 16 18 20 22,4
QVR.2. - CUN
C H
QVR.2 - CUN
Z B
Motor Power
P
m
(kW - 1500 min
-1
) / SF = 1,75
QVR.2L - CUN
Z B
E
B2
I
N
Nominal ratio
