Summer 07970C - Wall Cup Preparation and Attachment; Drilling and Wall Anchor Installation

8
x 4
Mark drill
holes with a
pencil through
the center
of each wall cup.
Mark drill
holes with a
pencil through
the center
of each wall cup.
x4
Place a wall cup over
the center of each circular
outline on the wall.
Place a wall cup over
the center of each circular
outline on the wall.
wall cup/top of stairs installation (continued)
1
st
Drill a 7/32
'
' pilot hole
into each of the 4
center marks.
Drill a 7/32'' pilot hole
into each of the 4
center marks.
2
nd
Insert wall anchors
into pilot holes.
Insert wall anchors
into pilot holes.
7
9
L
K
Note: If mounting into plaster or
drywall, follow this step and use
the wall anchors provided.
!
