REPLACEMENT PARTS LIST
Item Description Sizzler 26” Qty Sizzler 32” Qty Sizzler 40” Qty
1 TOP HOOD HOOD-SIZ26 1 HOOD-SIZ32 1 HOOD-SIZ30 1
2 TEMPERATURE GAUGE TEMP 1 TEMP 1 TEMP 1
3 TEMPERATURE GAUGE BEZEL TEMP BZL 1 TEMP BZL 1 TEMP BZL 1
4 HOOD BUMPER HOODBUMP-SS 2 HOODBUMP-SS 2 HOODBUMP-SS 2
5 HOOD HANDLE HOODHAND-SIZ26 1 HOODHAND-SIZ32 1 HOODHAND-SIZ40 1
6 WARMING RACK WARM-SIZ26 1 WARM-SIZ32 1 WARM-SIZ40 1
7 MAIN COOKING GRATE GRATE-SIZ 3 GRATE-SIZ 4 GRATE-SIZ 5
8 BURNER COVERS/BRIQUETTE TRAYS BRNCOV-SIZ 3 BRNCOV-SIZ 4 BRNCOV-SIZ 5
9 HEAT SHIELDS HEAT SHIELD-SIZ 3 HEAT SHIELD-SIZ 4 HEAT SHIELD-SIZ 5
10 CROSS TUBES CROSS TUBE-SIZ 2 CROSS-SIZ 3 CROSS TUBE-SIZ 4
11 MAIN BURNERS TUBE-SIZ 3 TUBE-SIZ 4 TUBE-SIZ 5
12 DRIP TRAY DRIP-SIZ26 1 DRIP-SIZ32 1 DRIP-SIZ40 1
13 REAR HOOD A REAR HOOD-SIZ26 1 REAR HOOD-SIZ32 1 REAR HOOD-SIZ40 1
14 REAR HOOD
–
B
(
COMES WITH 13
)
15 BASIN/FIRE BOX BASIN-SIZ26 1 BASIN-SIZ32 1 BASIN-SIZ40 1
16 NATURAL GAS REGULATOR
(
NG SETUP
ONLY
)
REG-SIZ-NG 1 REG-SIZ-NG 1 REG-SIZ-NG 1
17 MANIFOLD MAN-SIZ26 1 MAN-SIZ32 1 MAN-SIZ40 1
18 MAIN VALVES MV-SIZ-(NG OR LP) 3 MV-SIZ-(NG OR LP) 4 MV-SIZ-(NG OR LP) 5
19 BACK BURNER VALVE/ROTISSERIE
VALVE
N/A 0 BBV-SIZ 1 BBV-SIZ 1
20 FRONT PANEL FRONT-SIZ26 1 FRONT-SIZ32 1 FRONT-SIZ40 1
21 LOGO PLATE/ LOGO BADGE LOGO PLATE-SIZ 1 LOGO PLATE-SIZ 1 LOGO PLATE-SIZ 1
22 KNOB BEZEL KNOB BEZEL SIZ 3 KNOB BEZEL SIZ 5 KNOB BEZEL SIZ 6
23 KNOB KNOB-SIZ 3 KNOB SIZ 5 KNOB SIZ 6
24 BACK BURNER ELECTRODE COVER N/A 0 BBE-COV-SIZ 1 BBE-COV-SIZ 1
25 ROTISSERIE BURNER/IR BACK BURNER N/A 0 IR-BACKBRN-SIZ32 1 IR-BACKBRN-SIZ40 1
26 FLEXIBLE BACK BURNER GAS LINE N/A 0 FLEX TUBE-BB-SIZ32 1 FLEX TUBE-BB-SIZ40 1
27 BACK BURNER WIRE N/A 0 BBW-SIZ32 1 BBW-SIZ40 1
28 BACK BURNER ELECTRODE N/A 0 BBE-SIZ 1 BBE-SIZ 1
