Summerset SIZZLER - Page 19

12
5/8"
25
3/8"
9 5/8"
20 5/8"
10 1/2"
7 3/4"
LID HANDLE
LID
GRATE
IGNITER
BURNER
ORIFICE
BURNER BASE
BODY
VALVE
MANIFOLD
DRIP TRAY
KNOBS
KNOB BEZELS
FRONT PANEL
FLEX TUBE 200mm
FLEX TUBE 400mm IGNITER WIRE
330mm
IGNITER WIRE
480mm
BURNER PLATE
SIZZLER DOUBLE SIDE BURNER
PARTS LIST & LINE DRAWING
VALVE LATCH
16
