• Do not store or use gasoline or other
flammable liquids or vapors near this or
any other appliance.
• Do not store spare LP cylinders under or
near this appliance.
• Never fill cylinder more than 80%
capacity.
• If these instructions are not followed, fire
causing serious injury or even death may
occur.
• For installation in non-combustible
locations only.
• Do not locate under unprotected,
overhead combustible surfaces.
ENSURING PROPER COMBUSTION AIR AND
COOLING AIR FLOW
You must maintain proper air flow for your
Side Burner to perform as it was designed
(diagram below). If airflow is blocked,
overheating and poor combustion will result.
Make sure not to block the 1” (2.5 cm) front
air inlet along the bottom of the control panel
or more than 75% of the support grid surface
with pans or griddles.
Note: The 1” (2.5 cm) front air space allows access
to the drip tray.
EXHAUST REMOVAL
MINIMUM PRESSURE REQUIREMENTS
If installed under a patio roof, the cooking
grid area should be fully covered by a chimney
and exhaust hood. An exhaust fan with a
rating of up to 1,000 CFM (472 liters per
second) may be necessary to efficiently
remove smoke and other cooking by-
products from the covered area.
Installation in fully enclosed patio areas is
not recommended.
Ensure the gas supplied meets the minimum
pressure requirements. See below table for gas
requirements measured in water column (w.c.)
pressure:
Gas Type Maximum Minimum
Natural Gas 7” w.c. 4” w.c.
Liquid Propane 14” w.c. 11” w.c.
Both the regulator and burner orifices have
been tuned for the type of gas specified on the
rating plate. Converting to a different type of
gas requires a conversion kit. Conversion kits
are included with this Side Burner and
located with the manual. Converting gases may
require additional parts not included
with this Side Burner. (See Gas Conversion
section for details).
TRLSS
11-3/4"(W) x 9"(H) x 19"(D)
TRLSB2
11-3/4"(W) x 9"(H) x 19"(D)
SIZSB2
10-3/4"(W) x 8"(H) x 20-3/4"(D)
SSSB1
8"(W) x 2-1/2"(H) x 15-1/2"(D)
SIZPROSB2 10-3/4"(W) x 8"(H) x 20-3/4"(D)
ALTSB2
13-1/4"(W) x 10-1/4"(H) x 23-1/4"(D)
ALTSS
13-1/4"(W) x 10-1/4"(H) x 23-1/4"(D)
CUTOUT DIMENSIONS
TRLSS
15,000
TRLSB2
30,000
SIZSB2
SSSB1
24,000
SIZPROSB2 24,000
ALTSB2
35,000
ALTSS
26,000
TOTAL BURNER BTU'S
15,000
GAS SAFETY REQUIREMENTS
Each appliance is set and tested at the factory for
the type of gas supply to be used. Identify the
type of gas, either NG or LP (Liquid
Propane) gas and make sure that the marking
on the rating plate located on the side of the unit
matches the gas being supplied to the side
burner. The rating plate is located on the side of
the Side Burner.
All gas hook up connections should be made by
a qualified technician and in accordance with
local codes and ordinances. The installation
must conform with local codes or, in the absence
of local codes, with either the national Fuel Gas
Code, ANSI Z223.1/NFPA 54, or CAN/CGA-B149.1,
Natural Gas Installation Code or CAN/CGA-B149.2,
Propane Installation Code.
6
