Summit Audio TLA-50 - Page 9

Model TLA-50 Tube Leveling Amplifier
9
Applications
Basic In-line Connection of the TLA-50
Input Output
Channel
Input
TLA-50 MIC PREAMP
Mixer
OUTPUTS
CLASS A -TUBE LEVELER
MODEL TLA-50
SUMMIT AUDIO INC.
CARMEL, CA USA
115V 50/60 HZ
100V 50/60 HZ
INPUT
+4 BAL. -10 UNBAL.
LINK
INSERT
SIDE
CHAIN
+4 BAL. -10 UNBAL.
20
WATTS
MAX
FUSE
PUSH
OUTPUTS
CLASS A -TUBE PREAMP
MODEL
SUMMIT AUDIO INC.
CARMEL, CA USA
115V 50/60 HZ
100V 50/60 HZ
INPUT
+4 BAL. -10 UNBAL.
+4 BAL. -10 UNBAL.
20
WATTS
MAX
FUSE
PUSH
Inline Connection
