12
Built-in Under-counter Instructions
Make sure your installation does not block the front ventilation
grille. The unit is designed to fit under worktops, using the
height-adjustable ventilation grille to ensure that the feet are
concealed from front view.
If the unit is fully integrated to be installed for fitting kitchen
plinth, make sure that the ventilation gaps in the plinth are at
least 300 square centimeters and remove the ventilation
grilles, so that warm air can disperse unhindered. Otherwise
the appliance has to work harder, resulting in an increase in
electricity consumption.
NOTE: When pushing the appliance into the niche, make sure
that the mains cable does not get trapped.
NOTE:
1. Models LAWC1543, ADWC1552, SDW1527, LWC1547 and SDWC1556 have the same size as
ASDW1522.
2. Models LAWC2431, ADWC2442, SDW2416, LWC2435 and SDWC2446 have the same size as
ASDW2412.
Fully Integrated Built-in-Column Instructions
RISK OF DAMAGE! The wine cabinet has an elongated glass
door and must not be set down vertically at any time!
The unit door seals the installed unit almost completely, so an air
vent must be provided in the base of the housing. Warmed air
must be conducted via the ventilation shaft to the rear wall of the
housing and then expelled upwards. The ventilation channels
should measure at least 200 square centimeters in cross-
section.
WARNING: To ensure the proper functioning of the appliance, air vents should never be blocked or
covered.
WARNING: If the ventilation gaps given are not observed, the compressor will run more frequently
and for longer periods. This will result in increased energy consumption and a higher operating
temperature for the compressor. This may, in turn, cause damage to the compressor. It is essential
to observe the ventilation gaps given.
