Installation Instructions
DIMENSIONS AND CLEARANCES
Provide adequate clearances between the range and adjacent combustible surfaces. These dimensions must be met
for safe use of your range.
The range may be placed with 0" clearance below cooktop and at the back wall.
36”
¾ ± ¼”
Models
20” Wide
24” Wide
A
19¾”
23¾”
B
19¾”min
23¾” min
C
2”
2”
D
44⅜”
44⅜”
E
41¾”
41¾”
