Summit Solo Pro - Product Components and Requirements; Treestand Parts List; Required Tools for Assembly

1
INDEX
PG 2
GENERAL WARNINGS AND PRECAUTIONS, STAND WEIGHT LIMITS PG 1
SECTION 1 - INDEX PG 2
SECTION 2 - PARTS LIST PG 2
SECTION 3 - TOOLS REQUIRED PG 2
SECTION 4 - ASSEMBLY PG 3 - 8
SECTION 5 - SETUP AND USE PG 9 - 11
SECTION 6 - MAINTENANCE AND CARE PG 12
SECTION 7 - HARNESS SUSPENSION INFORMATION PG 12
SECTION 8 - LIMITED WARRANTY INFORMATION PG 12
2
PARTS LIST
BOX CONTENTS
PN DESCRIPTION QTY
82065.010 CROSS TENSION BAR 2
82065.020 LADDER SUPPORT 2
82065.200 PLATFORM BRACE 2
82065.100 PLATFORM 2
82065.300 YOKE 1
82065.400 LEFT SEAT SUPPORT 1
82065.450 RIGHT SEAT SUPPORT 1
82065.600 SEAT PAN 1
82065.910 TOP LADDER SECTION 1
82065.920 MIDDLE LADDER SECTION 1
82065.930 BOTTOM LADDER SECTION 1
82065.940 STABILIZER MALE SECTION 1
82065.950 STABILIZER FEMALE SECTION 1
82065.500 ARMREST 1
82065.820 LEFT GUNREST ARM 1
82065.830 RIGHT GUNREST ARM 1
82065.810 GUNREST BAR 1
82065.850 FOAM SEAT 1
82065.840 GUNREST PAD 1
82065.700 ACCESSORY PACKET 1
ACCESSORY PACKET CONTENTS
PN DESCRIPTION QTY
82065.890 HARDWARE PACKET 1
82065.750 PLATFORM RATCHET WITH
LOOP END 1
82065.755 PLATFORM SHORT STRAP
FOR RATCHET 1
82065.760 SHORT LADDER STABILIZER STRAP
WITH CAM BUCKLE 2
82065.765 LONG LADDER STABILIZER STRAP
WITH LOOP END 2
82065.870 INSTRUCTIONAL DVD 1
82065.880 4 POINT HARNESS WITH TREE
STRAP AND INSTRUCTIONS 1
STABILIZER BAR ROPE 1
3
TOOLS REQUIRED
Please call 256-353-0634 or visit http://www.summitstands.com/contactus/
if you have any questions, if you need replacement parts, if you have any missing parts or if the
included DVD does not play.
www.summitstands.com
Tools Use
• 7/16” Wrenches and / or Socket / Ratchet Main Ladder Bolts / Nuts -1/4x20 hardware
- Assembly can be made easier by the use of a powered ratchet or drill with socket adapter (take care not to overtighten
when using power tools to assemble)
- It is recommended that all bolts be sorted by thread count / length prior to assembly.
82065.890 - HARDWARE PACKET
All bolts used are 1/4” threads, grade 5.
PN DESCRIPTION QTY
10601 1 3/4” BOLT, 1/4x20 19
10670 2 1/2” BOLT, 1/4x20 14
2 3/4” BOLT, 1/4x20 4
10612 LOCK NUT, 1/4x20 37
1/4” WIRE LOCK PIN 3
1/4” BUSHINGS 2
RUBBER BUMPERS 4
NOTICE
Summit recommends the use of the SOP Climbing
System Accessory with all ladder and hang-on
treestands. For more information please visit our
website www.summitstands.com or by calling 256-
353-0634.
