34 Sun StorEdge 3000 Family Best Practices Manual • June 2004
1 Refer to Table 1 to determine how many physical drives can be included in one logical drive.
Full-Fabric SAN Tips and Techniques
■ In the fabric SAN configuration, the switches communicate with the array host
ports using a fabric point-to-point (F_port) mode. This enables transparent
controller fail-over and fail-back without server-resident software. However,
supporting hot-swap servicing of a failed controller requires the use of
multipathing software, such as the Sun StorEdge Traffic Manager, on the
connected servers.
TABLE 11 Configuration Overview for a Full-Fabric SAN
Small Configuration Medium Configuration Large Configuration
Sun StorEdge 3511 SATA array
Number of Servers 2 to 4 2 to 8 2 to 16
Cache Optimization Sequential Sequential Sequential
Sun StorEdge 3510 FC array
Number of Servers 2 to 4 2 to 14 2 to 30
Cache Optimization Random or sequential Random or sequential Random or sequential
Common Parameters
RAID Enclosures 1 1 1
Expansion Units As needed As needed As needed
Number of
Controllers
222
Number of Disks 12 or more 12 or more 12 or more
RAID Levels Application-dependent Application-dependent Application-dependent
Fibre connection
option
Point-to-point Point-to-point Point-to-point
Drive Configuration Two or more LUNs with
two or more global spares
1
Two or more LUNs with
two or more global spares
1
Two or more LUNs with
two or more global spares
1
Host Adapters per
server
Dual-port 2-Gbit FC Dual-port 2-Gbit FC Dual-port 2-Gbit FC
Traffic Manager Required Required Required
Storage Switches Two 8-port 2-Gbit
FC fabric switches
Two 16-port 2-Gbit
FC fabric switches
Two 32-port 2-Gbit
FC fabric switches
