Sun Moon SM-8800 - Default Chapter; Table of Contents

ᚹ࿪ࡊԫѣࢨΦ
ᚹ࿪ࡊԫѣࢨΦ
-1-
Table of Contents
1. General information
1-1 Standard configuration (Page2)
1-2 Specification (Page2)
1-3 Temperature protection (Page 3)
1-4 Front panel description (Page4)
1-5 Rear panel description (Page5)
2. Installation
2-1 SM-8800 power cord connection (Page6)
2-2 SM-8800 AC line connection (during self-coupling transformer adapted) (Page6)
2-3 SM-8800 connection with S.P.S. (Page7)
2-4 SM-8800 connection with oscillograph (Page7)
2-5 SM-8800 rear panel I/O Port connection with external control switch (Page7)
3. Operation panel description
3-1 Front panel description (Page11)
3-2 Display window description (Page12)
3-3 Rear panel description (Page13)
3-4 Keypad I1 ~ I10 setting and operation (Page14)
3-5 Read the result of AC Power Meter under manual operation mode
(※Only the model containing power meter works) (Page15)
3-6 Start the button function (Page 15)
4. Automatic test description
4-1 Test items specification (Page16)
5. Internal parameter Setting
5-1 Shift+A: Select Manual or Auto operation mode (Page21)
5-2 Shift+B: Set total test channels (Page24)
5-3 Shift+C: Set Auto- test parameters (Page25)
5-4 Shift+D: Set other shared parameters (Page33)
5-5 Shift+E: Fast set current in I1~I10 and maximum and minimum of voltage (Page41)
6. Deletion and Reset of machine parameters
6-1 Deletion and Reset of machine parameters, OPP retaining setting, and information setting by
downloader (Page 45)
2011/8/2 English Ver 1.38
