Sun Seeker e-DELTA - Front Wheel Installation; Rear Wheel Installation

6
C
4
Assembly Guide
Front Wheel Installation
1.Insert#4FrontWheelAssemblyintotheforkdropouts.SeeFigureC.
Rear Wheel Installation
1.Assemble#10RearWheelSpacer,#9RearWheelWasher,#6RearWheelAssemblyontoleftside(non-
driveside)rearaxle,using#8RearWheelOuterWasherand#7RearWheelNylocRetainingNutand
tighten.SeeFigureD.
2.Assemble#9RearWheelWasher,#5RearWheelAssemblyontorightside(driveside)rearaxle,using
#8RearWheelOuterWasherand#7RearWheelNylocRetainingNutandtighten.SeeFigureE.
NOTE:Donotovertightenthe#7RearWheelNylocRetainingNutontheLEFTside(non-driveside).
SeeFigureD.TheNutshouldbetightenedthenbackedoff1/2turntoleaveapproximately1to2mmof
sideplay.
E
5
7
8
9
D
6
7
8
9
10
